This machine is designed for tube film gusset, the gusset depth is around 25-100mm.
Machine is servo motor driven, with PLC controller.
Unwind with auto loading and auto tension controller. easy opeartion.
| Model | CP-600GS | CP-800GS |
| Width of jumbo roll | 600mm | 800mm |
| Dia of jumbo roll | 700mm | 700mm |
| Diameter of rewind | 1000mm | 1000mm |
| Max Depth of side gusset | 25-100mm | 25-100mm |
| Feeding speed | 20-250m/min | 20-250m/min |
| Total power | 3Kw | 3.5kw |
| Weight of machine | 1400kg | 1600kg |
| Dimension of machine | 2.6x1.8x3.2m | 2.8x2x3.4m |
CHOVYTING plastic bag making machine mainly includes automatic bag making machine, semi-automatic bag making machine, flat bag making machine and side-seal bag making machine and so on many types, you can choose the right model according to the production demand.
