This machine is producing rolling bag. Also can make star bag, garbage bag. Vegetable bag and table bag. Fully automatic exchange system can reduce the labor force, in the excellent servo driven system, it is the best choice for producing printed bag and blank bag. Easy for operate.
Main Features
1. Used 4 pcs servo motor driving ,improve the speed and stability.
2. Long time but low temperature sealing way ensures the quality of the bag.
3. Perforation line always keeps a same distance from the sealing line to ensure there won’t be any defect whenever in changing of different length.
4. Principles of sealing system uses swing, do not stop feeding.
5. Newly design paper core automatic feeding, positing and auto exchange new rolling.
| Model | CP-1000PR+C2+ST2 |
| Unwinder width | 1200mm Single line |
| Unwinder diameter | max.Φ1000mm |
| Length of bag making | 250-10000mm |
| Bag making speed | 250pcs/min |
| Max Depth of side gusset | 30-100mm |
| Line speed | Cored - 80m/min Coreless - 100m/min |
| Rewinding width | Cored - 600mm(Single line) 30Omm×2(Double line) Coreless - 600mm(Single line) 300mmx 2(Double line) Star seal bag maximum width 200mm (Doubleline) |
| Film unwind width | Maximum unwinding width when C folding 900mm |
| Max.diameter of rewinding | Cored-Φ160mm Coreless-Φ160mm |
| Finished roll exchange times | min. Coreless 6 rolls/min, min. Cored 4 rolls/min |
| Film thickness | HDPE 0.015-0.04mm LDPE 0.02-0.08mm |
| Total power | About 18.8KW |
| Machine dimension (LxWxH) | 8600X3600X1900mm |
| Machine weight | 2900kg |
| Air compressor | 6HP Excluding air compressor |
CHOVYTING plastic bag making machine mainly includes automatic bag making machine, semi-automatic bag making machine, flat bag making machine and side-seal bag making machine and so on many types, you can choose the right model according to the production demand.
